Function

Most applicable for storage and mixing of all kinds of liquid products when need insulation in dairy products, juice, beer and brew, chemistry, and biology engineering.

Material

All material used is high quality SUS 304 or 316L stainless steel, inner shell thickness δ=3-4mm and outer wall 2mm.

Structure feature

Isolated design (double layer), with 50-60mm PU as insulation; hcylindrica shape, triangle or cylinder legs. Agitator types:without agitator, wing agitator, wing agitator, anchor type; propeller type; frame type.

Standard attachments:

1.One air tight side manway;

2.Anti butterfly and dirt air vent;

3.One PT100 thermometer,temperature indication range 0-100℃;

4.CIP cleaning ball;

5.Product inlet/outlet;

6.Discharge valve with union;

7.Adjustable legs;

8.One sanitary sample valve
