 Hit:1426  Time:2016-07-20


Overview

Vertical milk cooling tank is mainly used in cooling and storage fresh milk or other liquid.It absorbs international advanced technology,adopts imported compressor with safety protection system,micro computer monitor,imported advanced technique and equipment such as polyurethane bubbling,honeycomb board evaporator.So it is the ideal cooling and storage equipment for farm,milk factory,food factory,and beverage factory and pharmacy industry.





Features

1.The tank wall use advanced dimple pad as evaporator exchange the heat directly with the milk inside.

2.The refrigeration compressor is imported of full closed compressor and imported expanding valve and electromagnetism valve.The system has reliable midpoint protection device to protect the compressor being burned result from the overloading or system trouble.

3.All of SUS 304 or 316L stainless steel, with CIP,cleaning ball and Auto-stirring system.

4.With high insulation by PU.



Technical Parameters

Model

Nominal Volume(L)

Tank

Weight (kg)

Agitator Motor (kw)

Agitator returning speed(rpm)

Length (mm)

Width (mm)

Height (mm)

KD-500

500

500

1060

1360

510

0.75

25

KD-1

1000

1000

1260

1510

640

1.1

35

KD-2

2000

2000

1660

1800

880

1.1

35

KD-3

3000

3000

1860

1960

1120

1.1

35

KD-5

5000

5000

2015

2100

1620

1.1*2

43

KD-8

8000

8000

2060

2200

1740

1.1*2

43

KD-10

10000

10000

2300

2500

2170

1.1*2

43
